Calibration: R-12, R-123, R-125, R-134a, R-143, R-22, R-404a, R-407c, R-410a, R-507, R-514a, R-1234yf, R-1234ze etc
Default calibration: R-404a
Sensor type: metal-oxide semiconductor
Sampling method: Diffusion
Sensor lifetime: > 5 years
Power supply: 24 VDC/AC ±20% (default) or 230 VAC (optional)
Digital interface: UART
Output relays: 2 × SPST relays (switch-over contact), 250 VAC / 30 VDC, 5A max
Alarms: blinking LED, buzzer 85 dB
Default alarm set points: 200 ppm / 400 ppm halocarbon gas
Enclosure: light-grey ABS plastic with ventilation slots, IP20
Dimensions: H85 × W85 × D36 mm
Operating conditions: -40...+70 °C, 0...95%RH
