Class: Bluetooth Low Energy (BLE)
Data Rate: 2 Mb/s
Frequency: 2.4 GHz
Dimensions: 15 mm x 10 mm x 2.2 mm
Sensitivity: - 92 dBm
Unit Weight: 420 mg
Output Power: 8 dBm
Interface Type: GPIO, I2C, SPI, UART, USB
Moisture Sensitive: Yes
Protocol - Sub GHz: NFC
Receiver Sensitivity: - 92 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.7 V
Antenna Connector Type: PCB
Operating Supply Voltage: 1.7 V to 3.6 V
Supply Current Receiving: 5.4 mA
Supply Current Transmitting: 14.1 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth 5.0
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
