Width: 5 mm
Height: 1.1 mm
Length: 6 mm
Fall Time: 2 ns, 3 ns
Rise Time: 2 ns, 4 ns
Technology: Si
Unit Weight: 207.730 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 25 nC, 67 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 21 W, 42 W
Vgs - Gate-Source Voltage: - 12 V, + 12 V
Typical Turn-On Delay Time: 8 ns, 13 ns
Typical Turn-Off Delay Time: 24 ns, 38 ns
Id - Continuous Drain Current: 60 A, 100 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 182 S, 241 S
Rds On - Drain-Source Resistance: 1.5 mOhms, 3.9 mOhms
Vds - Drain-Source Breakdown Voltage: 25 V
Vgs th - Gate-Source Threshold Voltage: 1.3 V, 1.5 V
