Faith FTP9900-1200-240 High-Power Programmable DC Power Supply (1200V, 240A, 80kW)

Voltage: 0～1200V

Current: 0～240A

Power: 0～80kW

Size (W x H x D): 482.6mm x 266mm x 738.0mm, includes protection cover, excludes casters

Weight: 65kg

Voltage rise slew rate

Maximum slew rate: 6000V/s

Voltage fall time

No load: ＜2s

Full load: ≤30ms

Transient response: Typical 2ms

Parallel: Parallel up to 10 identical units through master-slave mode for max 1800W output

Protection: OVP, OCP, OPP, OTP, LVP etc..

Interface: Standard LAN, USB(serial) (optional GPIB, CAN, RS485)

Protocol: SCPI, MODBUS, CAN-Open protocols

Input characteristics

Input voltage: 340VAC～460VAC, 47Hz～63Hz

Power factor: 0.99 (Typical)

Efficiency: ＞93% (Typical)

Operation environment

Working temp: 0℃～40℃

Storage temp: -20℃～70℃

Altitude: ＜2000m

Cooling: Air cooling
