Physical & Mechanical Properties
Dimensions (mm): 29 x 29 x 30 (excludes connectors and lens mount)
Weight (g): 36
Housing: Full
Sensor
Image Buffer: 240MB
Imaging Sensor: Sony IMX183
Type of Sensor: Progressive Scan CMOS
Type of Shutter: Rolling
Camera Sensor Format: 1"
Resolution (MegaPixels): 20.00
Pixels (H x V): 5.472 x 3.648
Pixel Size, H x V (μm): 2.4 x 2.4
Sensing Area, H x V (mm): 13.13 x 8.76
Frame Rate (fps): 18.00
Pixel Depth: 10/12 bit
Exposure Time: 67μs - 30s
Dynamic Range (dB): 71.89
Machine Vision Standard: USB3 Vision v1.0
Electrical
Power Consumption (W): <3
Hardware & Interface Connectivity
Video Output: USB 3.1 Gen 1
Connector: USB 3.1 Gen 1, Micro-B with Screw Locks
Power Supply: Power over USB or via GPIO with #88-063
GPIOs: 1 opto-isolated input, 1 opto-isolated output, 1 non-isolated bi-directional, 1 non-isolated input
Synchronization: Hardware Trigger (GPIO) or Software Trigger
Interface Port Orientation: Back Panel
GPIO Connector Type: 6-pin Hirose (HR10)
Threading & Mounting
Mounting Threads: ¼-20 with Tripod Mount Adapter #88-210
Mount: C-Mount
Environmental & Durability Factors
Operating Temperature (°C): 0 to +50
Storage Temperature (°C): -30 to +60
