General
Detector Type: Long-Life, Uncooled VOx Microbolometer
Focus Range: Athermalized, Focus-Free
Input Voltage: 24 VAC, Universal PoE Injector
Power Consumption: 12VDC, 2.5A, 30W 24VAC, 2.36A, 57VA 55VDC (PoE), 0.62A, 34W
Environmental
Humidity: 10 – 90% relative
IP Rating (dust & water ingress): IP66
Operating Temperature Range: -40°C – 55°C cold start
Shock: IEC 60068-2-27
Storage Temperature: -40°C – 85°C
Vibe: IEC 60068-2-64
Imaging & Optical
Visible Camera: 55° HFOV 30° VFOV 6mm focal length
Measurement & Analysis
Programmable Presets: 256
Other
Type of Sensor: Full HD 4K 1/1.8" Exmor R CMOS
PTZ
Pan Angle: Continuous 360°
Tilt Angle: -10° – 190°
System Integration
Ethernet: Yes
Network APIs: FLIR SDK, FLIR CGI, ONVIF Profile S
Streaming Resolution: Thermal: QVGA to VGA Visible: VGA to 4K
Supported Protocols: IPV4, HTTP, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
Thermal Camera
Optical Characteristic: FOV (H x W): 24° x 18° Focal Length: 18 mm
Pixel Pitch: 12 µm
Thermal Frame Rate: NTSC: 30 Hz PAL: 25 Hz / 8.3 Hz
Thermal Image Settings: Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
Video & Recording
Video Compression: Thermal: One channel of H.264 & M-JPEG Visible: Two independent channels of H.264 & M-JPEG
Video Thermal AGC Region of Interest [ROI]: Default, Presets and User definable to insure optimal image quality on subjects of interest
Visible Camera
Array format: 640 × 512
Sensitivity: Color: 0.25 Lux @(f1.6 AGC On, 30FPS) B/W: 0.10 Lux @ (f1.6 AGC On, 30FPS)
Spectral Range: 7.5 µm to 13.5 µm
