Image and optical data
IR resolution: 240 × 180 (43,200 pixels)
Thermal sensitivity/NETD: <0.06°C (0.11°F) / <60 mK
Spatial resolution (IFOV): 3.4 mrad
Field of view (FOV): 45° × 34°
F-number: 1.5
Image frequency: 9 Hz
Focus: Focus-free
Detector data
Detector type: Focal Plane Array (FPA), uncooled microbolometer
Spectral range: 7.5–13 µm
Image presentation and modes
Display: 3” 320 × 240 color LCD
Image adjustment: Automatic adjust/lock image
Image modes: Thermal MSX, thermal, picture-in-picture, thermal blending, digital camera
Color palettes: Iron, Rainbow, Black & White
Measurement and analysis
Object temperature range: -20°C to 550°C (-4°F to 752°F) in two ranges
Accuracy: ±2°C (±3.6°F) or ±2% of reading for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)
Spotmeter: Center spot
Area: Box with max/min
Isotherm: Above alarm, below alarm
Data communication and interfaces
Interfaces: USB Micro: data transfer to and from PC and Mac device
Wi-Fi: Peer-to-peer or infrastructure
File format: Standard JPEG, 14-bit measurement data included
General
Operating temperature range: -15°C to 50°C (5°F to 122°F)
Battery Rechargeable: 3.6 V Li ion battery
Battery operating time: Approx. 4 hours at 25°C (77°F) ambient temperature and typical use
Battery charging time: 2.5 hours to 90% capacity in camera. 2 hours in charger
Drop: 2 m (6.6 ft.)
Camera weight, incl. battery: 0.575 kg (1.27 lb.)
Camera size (L × W × H): 244 × 95 × 140 mm (9.6 × 3.7 × 5.5 in)
Box contents: Infrared camera, hard transport case, battery, USB cable, power supply/charger with EU, UK, US and Australian plugs, printed documentation
