IR Resolution: 320 × 240 (76,800 pixels)
Thermal Sensitivity/NETD: <0.04°C (0.07°F) / <40 mK at 30°C (86°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)
Field of view (FOV): 33°
Digital Camera: 5 MP
Image Modes: Thermal MSX, Thermal, Picture-in-Picture, Digital camera
Display: 3.5 in, 640 × 480 color LCD
Storage Media: Internal memory and onboard FLIR Ignite™ cloud connectivity (with Wi-Fi)
IMAGING & OPTICAL
Color Palettes: Iron, White hot, Black hot, Rainbow, Arctic, Lava, Rainbow HC
Detector Type: Uncooled microbolometer
Digital Camera: 5 MP
Field of view (FOV): 33°
Focus: Focus free
Gallery: Thumbnails and custom folder structure
Image Frequency: 9 Hz
Image Modes: Thermal MSX, Thermal, Picture-in-Picture, Digital camera
IR Resolution: 320 × 240 (76,800 pixels)
Minimum Focus Distance: 0.36 m (1.18 ft)
Spectral Range: 7.5 µm to 13 µm
Thermal Sensitivity/NETD: <0.04°C (0.07°F) / <40 mK at 30°C (86°F)
MEASUREMENT & ANALYSIS
Accuracy: ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)
Delta T: Yes, NFPA 70B compliant
Isotherm: Above alarm, below alarm
Measurements correction: Emissivity; matt/semi-matt/semi-gloss + custom value, reflected apparent temperature, atmospheric compensation
Object Temperature Range: -20°C to 550°C (-4°F to 1022°F) in two ranges
Spot Meter: Center spot; box with min/max
USER INTERFACE
Display: 3.5 in, 640 × 480 color LCD
Text: Text annotation on image using onscreen keyboard
Touchscreen: Capacitive touch
POWER
Battery operating time: 4 hours
Battery Type: Rechargeable Lithium-ion battery
Charging system: Battery is charged inside the camera or in specific charger
Charging Time: 2 hours
Power Management: Automatic shut-down
ENVIRONMENTAL
Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
Vibration: 2 g (IEC 60068-2-6)
GENERAL
Flashlight: Bright LED
List of Contents: Infrared camera, hard transport case, battery (inside camera) + extra battery, tabletop charger, power supply (with EU, UK, US and AU plugs), micro USB adapter, FLIR Thermal Studio Starter, and printed documentation
Packaging Size: 385 mm × 165 mm × 315 mm (15.2 in × 6.5 in × 12.4 in)
