Imaging & Optical
Adjustable Viewfinder: Built-in, tiltable OLED, 800 × 480 pixels
Camera f-number: 1.59
Color LCD: 4", 640 × 480 pixel rotatable, touchscreen LCD
Color Palettes: Arctic, White hot, Black hot, Iron, Lava, Rainbow, Rainbow HC
Detector Pitch: 30 μm
Detector Type: Focal plane array (FPA), cooled QWIP
Display Frame Rate: 60 Hz
Field of View: 14.5° × 10.8° (38 mm)
Focus: Manual or Automatic
Image Analysis: 10 spots, 5 boxes with max/min/average, 1 line (horizontal or vertical), measurement corrections
Image Modes: IR image, visual image, high sensitivity mode (HSM), noise reduction filter
IR Resolution: 320 × 240 pixels (76,800 pixels)
Laser Spot: Yes
MPEG Video Recording: Yes
Radiometric IR Video: RTRR (.csq), Over UVC
Radiometric JPG: Yes
Sensor Cooling: Stirling Microcooler (FLIR MC-3)
Spectral Range: 10.3 µm to 10.7 µm
Video Recording & Streaming: Real-time non-radiometric streaming: RTP/MPEG4
Visual Image: 3.2 MP from integrated visible camera
Zoom: 1 – 8× continuous, digital zoom
Measurement & Analysis
Accuracy: ±1°C (±1.8°F) for temperature range 0°C to 100°C (32°F to 212°F) or ±2% of reading for temperature range >100°C (>212°F)
Area Box: 5 (min./max./avg.)
Delta T: Yes
Gas Sensitivity: SF₆: <0.3 ppm x m (ΔT = 10°C, Distance = 1 m)
Measurement Corrections: Reflected temperature, distance, atmospheric transmission, humidity, external optics
Profile: 1 live line (horiz. or vert.)
Recording: MultiREC Recording; Record multiple files automatically in customizable order
Spot Meter: 10
Temperature Range: -40°C to 500°C (-40°F to 932°F)
Available sub ranges:
-40°C to 50°C (-40°F to 122°F)
-20°C to 120°C (-4°F to 248°F)
80°C to 250°C (176°F to 482°F)
150°C to 350°C (302°F to 662°F)
250°C to 500°C (482°F to 932°F)
Thermal Sensitivity: <15 mK @ 30°C (86°F)
Communication Interfaces: USB 2.0, Bluetooth via headset, Wi-Fi, HDMI
Image File Format: Standard JPEG, measurement data included. Infrared-only mode
GENERAL
Size [L x W x H ] w Lens: 251.6 mm × 164.5 mm × 170.9 mm (9.9 in × 6.48 in × 6.73 in)
Weight [incl lens & batteries]: 3 kg (6.18 lb)
Environmental & Certifications
Encapsulation: IP54 (IEC 60529)
Mounting: UNC ¼"-20
Operating Temperature Range: -20°C to 50°C (-4°F to 122°F)
Shock & Vibration: Shock: 25 g (IEC 60068-2-27); Vibration: 2 g (IEC 60068-2-6)
Storage Temperature Range: -30°C to 60°C (-22°F to 140°F)
