Accuracy : ±3°C or ±5%, typical Percent of the difference between ambient and scene temperature. Applicable 60 sec after start-up when the unit is within 15°C — 35°C and the scene is within 5°C — 120°C.
Non-Operating Temperature: -20°C — 60°C (-4°F — 140°F)
Scene Dynamic Range: -20°C — 120°C (-4°F — 248°F)
Spot Meter: Off / °C / °F. Resolution 0.1°C / 0.1°F
Thermal Sensitivity/NETD: 100 mK
Weight: 36.5 g
Dimensions (H x W x D): 68 × 34 × 14 mm (2.7 × 1.3 × 0.6 in)
Phone: Android (USB-C)
APP
Adjustable MSX distance: 0.3 m — Infinity
Battery charge monitor: 0 — 100%
Capture modes: Video, Still image, Time lapse
File Formats: Still images – radiometric jpeg Video – MPEG-4 (MOV)
Palette: Gray (white hot), Hottest, Coldest, Iron, Rainbow, Rainbow HC, Arctic, Lava and Wheel
Video: an Still Image Display/Capture Saved as 1440 × 1080
CONNECTIONS & COMMUNICATIONS
- Charging: Female USB-C (5V/1A)
- Video: Male USB-C
ENVIRONMENTAL & APPROVALS
- Emissivity Settings Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%, Glossy: 30%
- Mechanical shock: Drop from 1.8m
- Operating Temperature: 0°C — 35°C (32°F — 95°F) , battery charging 0°C — 30°C (32°F — 86°F)
IMAGING & OPTICAL
- Focus: Fixed 15 cm — Infinity
- Frame Rate: 8.7 Hz
- General Description: Thermal and Visual Cameras with MSX HFOV/VFOV: 50° ±1° / 38° ±1°
- Shutter: Automatic/Manual
- Thermal Resolution 80 × 60
- Thermal Sensor: Pixel size 17 µm, 8 — 14 µm spectral range
- Visual Resolution: 1440 × 1080
POWER
- Battery charge time: 40 min
- Battery Life: Approximately 1 hr
