IR Resolution: 464 x 348 (161,472 pixels)
Thermal Sensitivity/NETD: <30 mK at 30°C (42° lens)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Field of View (FOV): 80° × 63°
Digital Camera: 5 MP, with built-in LED photo/video lamp, disabled when 80° lens in use
Display: 4", 640 x 480 pixel touchscreen LCD with auto-rotation
Storage Media: Removable SD card
IMAGING & OPTICAL
Color Palettes: Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Detector Type and Pitch: Uncooled microbolometer, 17 µm
Digital Camera: 5 MP, with built-in LED photo/video lamp, disabled when 80° lens in use
Digital Zoom: 1-6x continuous
f-number: 1.3, 80°
Focal length: 5 mm (0.19 in)
Focus: Continuous with laser distance meter (LDM), one-shot LDM, one-shot contrast, manual
Image Frequency: 30 Hz
IR Resolution: 464 x 348 (161.472 pixels)
Lens Identification: Automatic
Minimum Focus Distance: 0.1 m (3.9 in)
Non-radiometric IR video streaming: H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi
Picture-in-Picture: Resizable and movable
Radiometric IR video recording: Real-time radiometric recording (.csq)
Radiometric IR video streaming: Yes, over UVC or Wi-Fi
Spectral Range: Dependent on the IR resolution of the camera: 320 × 240 pixels: 5.2mrad/pixel 464 × 348 pixels: 3.6 mrad/pixel 640 × 480 pixels: 2.6 mrad/pixel
Spectral range: 7.5 - 14.0 µm
Thermal Sensitivity/NETD: <30 mK at 30°C (42° lens)
UltraMax: Quadruples pixel count; activated in menu and processed in FLIR Tools
Viewfinder: Yes
MEASUREMENT & ANALYSIS
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Measurement Presets: No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2
Object Temperature Range: -20°C to 120°C (-4°F to 248°F); 0°C to 650°C (32°F to 1202°F); 300°C to 1500°C (572°F to 2732°F)
Spot Meter: 3 ea. in live mode
USER INTERFACE
Display: 4", 640 x 480 pixel touchscreen LCD with auto-rotation
Text: Predefined list or touchscreen keyboard
Voice: 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth
POWER
Battery operating time: Approx. 4 hours at 25°C (77°F) ambient temperature and typical use
Battery Type: Li-ion battery, charged in camera or on separate charger
ENVIRONMENTAL
Operating Temperature Range: -15°C to 50°C (5°F to 122°F)
Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
