Fluke (Calibration) 5540A Multi-Product Calibrator

Direct volts: 0 V to ± 1020 V

Direct current: 0 to ± 30.2 A

Alternating volts: 1 mV to 1020 V; 3 Hz to 500 kHz

Alternating current: 10 μA to 30.2 A; 3 Hz to 30 kHz

Volt/hertz: 1000 V at 10 kHz/330 V at 100 kHz

Waveforms: Sine wave, triangle wave and truncated sine wave

Resistance variable: 0 Ω to 1200 MΩ

Capacitance variable: 200 pF to 120 mF

Inductance variable: 12 uH to 12 H

Power (dual output – phantom loads): 30.9 kW

Oscilloscope bandwidth: 2.1 GHz, 1.1 GHz, or 600 MHz

Phase lock: Yes

Phase control: 0.01°

Frequency uncertainty: <2.5 ppm

Temperature standard: <ITS-90, IPTS-68

Resistance temperature detectors: Pt100 385, Pt100 395, Pt100 3916, Pt200 385,

(RTDs) output: Pt500 385, Pt1000 385, Ni120, Cu10 Compensation: off, 2-wire, 4-wire

External frequency reference 10 MHz: Yes

Thermocouples (source and measure): B,C,E,J,K,L,N,R,S,U, BP and XK

External or internal CJR: 10 μV/°C

Scope calibrator: SC600 – with levelled sine up to 600 MHz; SC1100 – with levelled sine up to 1100 MHz; SC2100 – with levelled sine up to 2100 MHz

Interfaces / Remote commands: USB 2.0, Etherne Telnet, RS-232 and GPIB

52120A Amplifier current capability: Current capability up to 120 A; Current capability up to 360 A with three;  52120As (parallel)
