AC volts: (4.000 V, 40.00 V, 400.0 V, 1000 V)/(1.0 % + 3)
DC volts: (4.000 V, 40.00 V, 400.0 V, 1000 V)/(0.5 % + 3)
AC mV: 400.0 mV/3.0 % + 3
DC mV: 400.0 mV/1.0 % + 10
Diode test: 2.000 V/10%
Resistance (Ohms): 400.0 Ω/ 0.5 % + 3; (4.000 kΩ, 40.00 kΩ, 400.0 kΩ, 4.000 MΩ)/0.5 % + 2; 40.00 MΩ/1.5% + 3
Capacitance: (40.00 nF, 400.0 nF)/2 % + 5; (4.000 μF, 40.00 μF, 400.0 μF, 1000 μF)/5 % + 5
Frequency: (50.00 Hz, 500.0 Hz, 5.000 kHz, 50.00 kHz, 100.0 kHz)/0.1 % + 3
AC current μA: (400.0 μA, 4000 μA)/1.5 % + 3
AC current mA: (40.00 mA, 400.0 mA)/1.5 % + 3
AC current A: (4.000 A, 10.00 A)/1.5 % + 3
DC current μA: (400.0 μA, 4000 μA)/1.5 % + 3
DC current mA: (40.00 mA, 400.0 mA)/1.5 % + 3
DC current A: (4.000 A, 10.00 A)/1.5 % + 3
Temperature: 50 °C- 400 °C/2 % ± 1 °C, 0 °C- 50 °C/± 2 °C,-55 °C- 0 °C/ 9 % ± 2 °C
Overload Protection:
+ AC volts: 1000 V
+ AC mV: 400 mV
+ DC volts: 1000 V
+ DC mV: 400 mV
Battery type: 2 AA, NEDA 15A, IEC LR6
IP rating: IP 40
Size (HxWxL): 183 x 91 x 49.5 mm
Weight: 455 g
