Psi range, resolution: -12.0000 to 300.0000 psi
Bar range, resolution: -0.8273 to 20.6843 bar
kPa range, resolution: -82.73 to 2068.43 kPa
Comment: Wireless communication for Fluke Connect
Electrical specification:
Ranges:
mA measure, source and simulate: 0 mA to 24 mA
Volts dc measure: 0 V dc to 30 V dc
Resolution mA dc source, simulate and measure: 1 μA
Voltage dc measurement: 1 mV
Accuracy: 0.01% ±2 LSD all ranges (at 23 °C ±5 °C)
Stability: 20 ppm of full scale /°C from -10 °C to +18 °C and 28 °C to +50 °C
mA simulate external voltage requirement: 12 V dc to 30 V dc
Loop compliance voltage: 24 V dc @ 20 mA
mA simulate external voltage requirement: 12 V dc to 30 V dc
Temperature measurement only/100 Ω Pt(385) RTD: -50 °C to 150 °C (-58 °F to 302 °F)
Temperature resolution: 0.01 °C (0.01 °F)
Temperature accuracy: ±0.1 °C (0.2 °F) ±0.25 °C (±0.45 °F) combined uncertainty when using 720 RTD probe (optional accessory)
Drive capability: 1200 Ω without HART resistor, 950 Ω with internal HART resistor
Mechanical specification
Size (HxWxL): 7 x 27.94 x 17.27 cm (2.75 x 11 x 6.8 in)
Weight: 6.5 lbs., 2.95 kg
Ingress protection: IP54
Environmental specification
Operating temperature: -10°C to 50°C for measurement, 0°C to 50°C for pressure control
Operating temperature with battery: -10 °C to 40 °C
Battery will only charge to 40°C
Storage temperature: -40°C to 60°C
