Thermal Resolution: 160*120
Super Resolution(SR): 320*240
Thermal Sensitivity(NETD): 60mk(0.06°C)
Lens Options(Not interchangeable):
49°x 36.8°, IFOV: 5.15 mrad, Focal length: f/3.3, Minimum Focus Distance: 0.1m
25°x 19°, IFOV: 2.73 mrad, Focal length: f/7.5, Minimum Focus Distance: 0.1m
Focus Mode: Manual focus, and 0.5 meters focus free (available for 49° and 46.5° lens)
Frame Rate: 30Hz
Temperature Analysis
Temperature Range: -20°C ~ 120°C，0°C ~ 550°C (-4°F~248°F, 32°F~1022°F)
Measurement Tools: Spot: 6; Line: 1; Rectangle/Circle: 4
Measurement Accuracy: ±2 °C or 2% , whichever is greater (at 25 °C ambient temperature
Image Display
Display Screen: 3.5 inch Touch Screen
Image Mode: Thermal, Visible light, Picture in Picture & Image Fusion
Palettes: 8, Grey, Iron, Rainbow, Grey-red, Rain, GlowBow, Medical, Prism
Minimum Temperature Span: Auto:3°C , Manual:2°C
Storage & Analysis
Storage Card: TF card, 64GB
File Format: Radiometric thermal photo(JPEG.), visible light photo, radiometric thermal video(IRS.) and MP4 video
Voice Annotation: Support, record up to 120 seconds; via Mic or Bluetooth headset
Tags: Support, Manual input and QR-code scan
Power System
Battery: 3.6V, 5000mAh Li-battery
Battery operation time: ≥5 hours
Battery charging time: 3.5 hours to full-charge by battery dock. 3 hours to full-charge by connectting to camera.
General Specifications
Spectral range: 7-14μm
Detector Pitch: 17μm
Digital Zoom: 1-8 times, continuous
Laser pointer: Level2; wavelength: 635nm; Power:<1mW
Operation temperature: -40°C to 70°C, without battery
Humidity: <95%RH
Drop: Designed for 2 meters drop test. (GB/T 2423.8/IEC 60068-2-32)
Dimension: 243mm*95mm*142mm
Weight (include battery): 730g
Enclosure rating: IP54
