Width: 6.3 mm
Height: 3.6 mm
Length: 4.75 mm
Rise Time: 300 us
Output Type: Photodarlington
Unit Weight: 260 mg
Configuration: 1 Channel
Mounting Style: Through Hole
Isolation Voltage: 5300 Vrms
Number of Channels: 1 Channel
If - Forward Current: 60 mA
Vf - Forward Voltage: 1.4 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 600 %
Pd - Power Dissipation: 250 mW
Maximum Collector Current: 80 mA
Current Transfer Ratio - Min: 600 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
Maximum Collector Emitter Voltage: 35 V
Maximum Collector Emitter Saturation Voltage: 100 mV
