Model: GT-RC06A
Control Mode: Touch screen
Laser Pyrometer Range: ≥ 700–1800°C
Emissivity Range: ≥ 0.100–1.100
High-Frequency Heating Device for Metal Heating:
Output power ≥ 6 kW, max. temperature ≥ 1800°C, distance from the pouring position < 30 cm; pouring temperature can be set, monitored and controlled in the software.
Frequency Range of the High-Frequency Heating Device: ≥ 150–450 kHz
Molten Metal Pouring Device: Sample holder with coupling, height/angle adjustable, rotation angles 0°, 60°, 70°, 75°.
PVC Film Calibration Device: EN ISO 9185
Cooling Method: Water cooling
Environment: 10–30°C
Installation: Floor standing
Customer-Supplied:
Suction hood smoke exhaust device;
Tap water (inlet & outlet) or optional chiller;
Balance 1000 g, accuracy ±1 g;
Muffle furnace or high-temperature drying oven (for PVC film calibration);
Protective equipment: protective gloves, protective face shields, aprons, leg guards.
Power Supply: Three phase 380V, 50Hz, 6000W
Dimension: 130 × 96 × 160 cm (L × W × H)
Weight: Around 360 kg
Accessories
Standard Accessories:
Touch Program Controller: 1 set
Optical Pyrometer: 1 pc
High-Frequency Generator: 1 pc
High-Frequency Induction Furnace: 1 pc
Crucibles: 1 pc
Sand Table: 1 pc
Foot Switch: 1 pc
ISO 9185 PVC Film (5 meters): 1 roll
ISO 9185 PVC Film Calibration Device: 1 pc
Optional Accessories:
Chiller Unit: Optional
This PPE testing equipment used for testing molten aluminum splash resistance Class D, molten iron splash resistance Class E, etc., of fabrics such as heat-insulating protective clothing and heat-insulating gloves.
