ELECTRICAL PARAMETERS
Accuracy class: 0.05%, 0.1%
Power supply: Single phase AC 220V±10% or 110V±10%, 50/60Hz
Communication port: USB, RS232, RS485, LAN
AC Voltage output
Range(U1,U2,U3): 50V, 100V, 200V, 400V, 600V
Adjustment range: (0 - 120)% RG
Adjustment resolution: 0.01% RG, 0.1% RG, 1% RG, 10% RG
Stability: 0.01% /1min
Distortion: ≤0.2% (non-capacitive load)
Max. output load: 25VA for each phase
Accuracy: 0.05% RG
AC Current output
Range(I1,I2,I3): 0.5A, 1A, 2.5A, 5A, 10A, 20A
Adjustment range: (0 - 120)% RG
Adjustment resolution: 0.01% RG, 0.1% RG, 1% RG, 10% RG
Stability: 0.01% /1min
Distortion: ≤0.2% (non-capacitive load)
Max. output load: 25VA for each phase
Accuracy: 0.05% RG
AC Power output
Active output stability: 0.01%RG/1min
Reactive output stability: 0.02%RG/1min
Active accuracy: 0.05% RG
Reactive accuracy: 0.1% RG
Frequency output
Adjustment range: 45-65Hz
Adjustment resolution: 1Hz, 0.1Hz, 0.01Hz and 0.001Hz
Resolution: 0.001Hz
Accuracy: 0.002Hz
Power factor output
Adjustment range: -1 to 0 to +1
Adjustment resolution: 0.0001
Resolution: 0.0005
Phase output
Adjustment range: 0°-359.999°
Adjustment resolution: 10°, 1°, 0.1°, 0.01°
Resolution: 0.001°
Accuracy: 0.05°
Harmonic configuration
Times: 2 to 31
Content: 0-40%
Phase: 0°-359.999°
Configuration error: (10% RD + 0.1%), RD refers to the configuration value of harmonic contents
DC Voltage output
Range: 75mV, 75 V, 150 V, 300 V, 500V, 1000 V
Adjustment range: (0-120)% RG
Adjustment resolution: 0.01% RG, 0.1% RG, 1% RG, 10% RG
Stability: 0.01% RG / 1 min
Distorting: ≤0.2% (non-capacitive load)
Output load: 25VA
Accuracy: 0.05% RG
Ripple contents: ≤1%
DC Current output
Range: 0.5 A,1A, 2.5 A, 5 A, 10A, 20 A
Adjustment range: (0-120)% RG
Adjustment resolution: 0.01% RG, 0.1% RG, 1% RG, 10% RG
Stability: 0.01% RG / 1min
Distortion: ≤ 0.2% (non-capacitive load)
Output load: 25VA
Accuracy: 0.05% RG
Ripple contents: ≤1%
Energy Error
Active error: 0.05% RG
Reactive error: 0.1% RG
DC Input Voltage Measurement
Range: 0 to ±20V
Measurement range: (0-120)% RG
Accuracy: 0.01% RG
Resolution: 0.001% RG
DC Input Current Measurement
Range: 0-20mA
Measurement range: (0-120)% RG
Accuracy: 0.01% RG
Resolution: 0.001% RG
MECHANICAL PARAMETERS
Dimensions (W×H×D) (mm): 460x430x185
Weight (kg): 20
ENVIRONMENTAL CONDITIONS
Working temperature: 0°C to 40°C
Relative humidity: ≤85%
