ELECTRICAL PARAMETERS
Rate Current: 250A
Max Current: 300A
Secondary current: 250mA
Ratio: 1000:1
Accuracy: 0.1%
Over voltage category: CAT III 600V
Output signal (AC current): 250mA, 500mA,1A,5A AC at nominal input current
Output signal (AC voltage): 1V, 5V, 10V AC at nominal input current
Frequency range: 40Hz-2000Hz
Dielectric strength: 3KV 50Hz/60Hz at 1 minute
Temperature range: '-40°C to +55°C
Output: 2.5 meter cable with D01 connector
Max. voltage not insulated conductors: 600 V
Standard: EN 61010-1, EN 61010-2-032, IEC60044-1, IEC61869-2
Installation: clamp type
Output mode: lead output(2.5m, 5m or 10m)
MECHANICAL PARAMETERS
Dimensions (L x W x H) (mm): 163 x 310 x 34
Weight (g): 900
Holding wire diameter (mm): φ110
Max. jaw opening (mm): 110
Jaw color: Black
Material: PC+ABS, UL94 V0
