Typical responsivity: 12 nA/lx
f1' (spectral mismatch): f1' ≤ 3% (CIE: Class 3*, DIN EN 13032-1: Class A)
f2 (directional response/cosine error): f2 ≤ 6% (CIE: Class 1*, DIN EN 13032-1: Class C)
f6 (temperature):
DIN EN 13032-1: Class L ≤ 0.15%
CIE: Class 4*: ≤ 0.75%
Max. signal current: 1 mA
Input optics: Diffuser window 30 mm Ø
min. signal current: depends on optometer
Measurement ranges: Recommended measuring range in combination with Optometer P-9710 <100 μlx to> 80,000 lx
Rise time: 33 µs
Illuminance measurement range (integral measurement):
83000 lx: 1 mA
16000 lx: 200 µA
Miscellaneous:
Temperature range: 5 - 40°C
Connector: coaxial cable 2m Long, with BNC connector (VL-3707-1)
Dimensions
Diameter: 37 mm (+Connector)
Height: 21 mm
