Gigahertz-Optik X1-1 Handheld Multi-Channel Optometer (256 data sets, 200.0 µA ~ 200.0 pA) | EMIN.COM.MM

Gigahertz-Optik X1-1 Handheld Multi-Channel Optometer (256 data sets, 200.0 µA ~ 200.0 pA)

Name: Gigahertz-Optik X1-1 Handheld Multi-Channel Optometer (256 data sets, 200.0 µA ~ 200.0 pA)
Brand: Gigahertz-Optik

ManufacturerGigahertz-Optik(View more products from this manufacturer)

ModelX1-1

P/N15298890

OriginGermany

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Measurement range: Wide dynamic current measurement range from 0.1 pA (noise equivalent signal) up to 200 µA. Seven gain ranges with manual or automatic selection. Measurement range in absolute units with given by the detector heads responivity and calibration.

Calibration: Calibration and comparison of the current responsivity in each of the seven gain ranges. Memory for calibration data of several detector heads for measuremen in the absolute unit of the selected detector head.

Detector interface: 9pin MDSM9 socket, 4 inputs

Measurement range: 200.0 µA ~ 200.0 pA

CW integration time: 1 ms – 1 s

Sampling rate: internal sampling rate ADC 250 µs

Offset correction: Correction range transcending

Parameter adjustment: Remote control or front panel buttons (menu), set values permanently stored (EEPROM)

Calibration:

X1-1: max. 256 data sets (one data set can include up to 4 channel entries) total stored in device EEPROM

Dose:

The maximum dose to be displayed on the X1-5/1 device is 99999 TJ/cm² (for W/cm²) or 99999 TJ/m² (for W/m²)

Maximum time to be set for dose measurement: 255h 59min 59s

Power Supply:
