Direct access to our certified experts
Connection Values
Mains connection: 4 mm safety sockets
Nominal voltage: 3 x 230/400 V
Frequency: 50/60 Hz
Protection class: I
Circuits
Lamp circuit E1: Disconnection, including LED lamp
Mains outlet circuit: X1
CEE outlet: X2
F1: Circuit breaker B10
F2: RCD/MCB combination, IΔN = 10 mA
F3.0: Residual current circuit breaker, type B, IΔN = 30 mA
F3.1 ... 3.3: Circuit breaker B16
Mechanical Design
Dimensions: 297 x 456 x 80 mm
Weight: Approx. 3.2 kg
Inputs/outputs: 4 mm safety sockets
Ambient Conditions
Ambient temperature: Max. +35 °C
Relative humidity: Max. 60%, condensation is ruled out
