Earth Continuity
Method: 2-wire measurement with high current pre-pulse (65-25A peak).
Measuring Range (Low Range): 0.001 – 0.999Ω; Resolution: 0.001Ω
Measuring Range (Mid Range): 1.00 – 9.99Ω; Resolution 0.01Ω
Measuring Range (High Range): 10.0 – 19.9Ω; Resolution 0.1Ω
Accuracy: ± 1% of value, ± 5mΩ; ± 1% of value, ± 5mΩ
Insulation Resistance
Insulation Resistance Test: Performed at 500 VDC @ 1 mA (EUT to Earth).
Range: 100K – 20MΩ ± 5% ± 2 digits; Resolution: 0.01MΩ
Powered Leakage Measurements
Powered Leakage Types: Equipment (Direct), Earth + Enclosure, Ground + Chassis, and Touch leakage.
Measuring Range: 0.1 - 9999μΑ (0.1 - 8000μA typical for IEC61010)
Measurement/Display Resolution: 0.1μΑ
Accuracy: ± 2%, ± 5μΑ
Voltage Measurement
Application: L-N, L-E, N-E and touch voltage
(IEC 61010)
Range: 0.0V – 300VAC
Resolution: 0.1V
Accuracy: ± 2% ± 5 digits (between 10V – 270VAC)
EUT Load Current Measurement
Range: 0.0A – 20.0A
Resolution: 0.1A
Accuracy: ±5% ± 2 digits
Power Source: 90-264V AC, 48-64Hz
Maximum Current Rating: 20A @ 120V or 16A @ 230V.
Ingress Protection: IP 40 rating.
Dimensions: Compact size at 225 x 150 x 100 mm (9 x 6 x 4”).
Net Weight: Extremely portable at 1.1 kg (2 lbs) for the main unit.
