Wavelength: 1310/1550/1650nm
Dynamic Range: 22/20/20dB
Dead-zone: 1/4m
Test Range: 500m~120km
Pulse Width: 3ns~10us
Test Time: 5s~180s
Test Mode: Auto, Manual, Real-time
Sampling Point: 30000
Distance Accuracy: ±(1m+Test distance×3×10^-5 +Sampling resolution) (excluding IOR uncertainty)
VFL:
Working wavelength: 650±10nm
Output power: 10mW, CW/1Hz/2Hz
Stable OLS:
Working wavelength: Consistent with OTDR
Output power: >-12dBm, CW/270Hz/1kHz/2kHz
Normal OPM (Standard)
Calibrated wavelength: 850/1300/1310/1490/1550/1625/1650nm
Test range: -40~+10dBm
10G PON Selective OPM (Optional)
Support 1490nm and 1577nm selective power testing separately
Calibrated wavelength: 850/1300/1310/1490/1550/1577/1625/1650nm
Optical Interface
OTDR/OLS: Fixed SC/UPC (APC is available)
VFL/OPM: 2.5mm universal port
Electrical Interface: USB Type-C charging port and data port
Display: 4inch color touch screen
Data Storage: 120M storage card
Battery: 4000mAh lithium battery
Working Environment: -10℃~+50℃; 0~85%(non condensing)
Dimension/Weight: 85x148x37mm/275g
