Technical
Speed no: 1
Max. flow: 3.9 m³/h
Maximum head: 4.6 m
Approvals
UL, CSA
Materials
Pump housing: Bronze (EN 2.1176.01)
Impeller: Composite, PES
Installation
Maximum ambient temperature: 40 °C
Ambient max at 80 °C liquid: 80 °C
Maximum operating pressure: 10 bar
Type of connection: USA Sweat / Brz. Sweat
Pipe connection: 1/2" Sweat
Pressure rating for connection: PN 10
Port-to-port length: 127 mm
Terminal box position: 9H
Liquid
Pumped liquid: Water
Liquid temperature range: 2 .. 110 °C
Selected liquid temperature: 60 °C
Density: 983.2 kg/m³
Electrical Data
Max. power input: 85 W
Mains frequency: 60 Hz
Rated voltage: 1 x 115 V
Current in speed 3: 0.74 A
Number of poles: 2
Insulation class (IEC 85): F
Ex-protection standard: CONTACT
Thermal protection: Internal
Controls
Terminal box position: 9H
Others
Gross weight: 2.72 kg
