Imaging and optics:
Core Technology Item : Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0
Detector type : VOx, 7.5 to 14μm
Infrared resolution : 320×240@12μm
Super resolution : Yes, Upgrade to 640×480
NETD : 15mK
Frame rate : 50Hz/9Hz
Focal length: 8.5mm
Field of view : 25°×19°
IFOV: 1.36mrad
Min. object distance : 0.15m
D:S : '735:1
Focusing mode : Manual / Automatic / Touch autofocus / Continuous autofocus
Digital zoom : 1.1x to 8x
Measurement and analysis:
Measurement range : Support auto-switching: -40°C to 150°C, 0°C to 650°C, 500°C to 2000°C (RangeMax Ultra-wide measurement range lens kit is required)
Measurement accuracy : ±2°C or ±2%, whichever is greater
Analyzed target: 8 in total (Spot/Line/Area)
Alarm : Full screen temperature threshold alarm (Image, Voice, Color and Flash)
Others : Isothermals, Smart stroke, Intelligently calculate the area, Color highlighting
Image display:
Display screen : 4.3" LCD, touch screen, 800×480
Image mode: IR, VIS, MIF, PIP
Color palettes : 15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber
Image adjustment : Level span mode: Automatic, Semi-automatic, Manual, Local dimming
Digital camera : 5MP
Functions:
Laser: Laser indication; Laser ranging 0.1m to 40m
Recording function : Photo and Video
Cloud Services : Available
Others: Customized physical button, OTA update
Storage and transmission:
Storage media : Built-in (64 GB) and external SD card (64 GB and up to 256 GB)
Image storage : JPG with temp info
Video storage : MP4 format (without temp info) can be used to record audio synchronously; Irgd (with temp info), up to 50 Hz (optional) for temperature analysis
External interface : USB-C, SD card slot, Tripod socket
Wi-Fi : Yes, it can be connected to the mobile terminal for image and real-time video transmission
Bluetooth : Bluetooth 5.0, support image transmission (only for Android)
Power system:
Battery type : Lithium-ion rechargeable battery
Operating time : 5 hours
Environmental parameters:
Working temperature : -20°C to 50°C
IP rating : IP54
Drop : 2m drop test
Physical parameters:
Hardware : Wi-Fi, Illuminator×2, Microphone, Speaker, Electronic Compass, GPS
Weight : 1.24KG (with standard lens and battery)
Size : 292×125×125mm
Software kit: PC: ThermoTools; Mobile: FocusIR (iOS/Android)
Standard: A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C cable, USBA to USB-C cable, USB-C to Ethernet Adapter, SD card (64 GB) , Wrist strap, Shoulder strap, Carrying bag, Safety box, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate
Options: Optional lenses: Wide-angle (44°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), RangeMax Ultra-wide Kit (25° / 15° / 7°); Tripod, Docking station, Ethernet cable
