Imaging and optics
Detector type: VOx, 7.5 to 14μm
Infrared resolution: 480 × 360@12μm
Super resolution: Yes, Upgrade to 960 × 720
NETD: ≤45 mK
Infrared frame rate: 30 Hz / 9 Hz
Focal length: 17.7 mm
Field of view: 25° × 19°
IFOV: 0.91mrad
Minimum object distance: 0.15m
D:S: 1099:1
Focusing mode: Manual / Automatic / Continuous autofocus
Digital zoom: 1.1x to 16x
Shot recognition: Auto
Measurement and analysis
Measurement range: Support auto-switching: -40°C to 150°C, 0°C to 650°C, Optional 500°C to 2000°C (High temperature lens is required)
Measurement accuracy: ±2°C or ±2%, whichever is greater
Analyzed target: Spot×12, Line×12, Area×12
Temperature measuring: parameters Emissivity, reflected temperature, target distance, humidity, atmospheric transmittance, optical transmittance, dew point
Others: Isothermals, Smart Stroke, Intelligently calculate the area
Image display
Display screen: 4.3’, 800×480 pixel touchscreen LCD
Digital camera: 8 MP
Image mode: IR, VIS, MIF, PIP
Image adjustment: Level span mode: Automatic, Semi-automatic, Manual
Color palettes: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized
Power system
Battery type Lithium-ion rechargeable battery
Battery working time ≥4 hours
Charging mode TYPE-C charging; PC/portable charger; Capable of charging while using
Charging time 90% of full charge in 2.5 hours
Environmental parameters
Working temperature -20°C to 50°C
Storage temperature -40°C to 60°C
IP rating IP54
Drop 2m drop test
Certification CE, FCC, ROHS, KCC, Anatel, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS
Physical parameters
Hardware Laser (Indication, Ranging 0.1m to 40m), Illuminator, Microphone, Speaker, Electronic Compass, GPS
Weight ≤1.15KG (with battery)
Size (L × W × H) 292 × 125 × 125 mm
Software kit PC: ThermoTools; Mobile: Thermography (iOS/Android)
Standard
A device (with lens), Front and lens covers, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug (for China, US, UK, Australia and Europe), Cable (double-headed TYPE-C USB), TYPE-C USB cable, Ethernet Cable, TYPE-C to RJ45, SD card (64 GB) , Wrist strap, Shoulder strap, Safety box, Packaging list, Quick Start Guide, Data download card (analysis software & user manual), Certificate of approval, Factory certificate
Options
Battery, optional lens (44°, 15°, 7°, 25°, high-temperature lens, macro lens), Carrying bog, Tripod, Bluetooth earphone, Docking station
