Imaging Performance
IR resolution: 384×288
Spectral Range: 7.5~14μm
Pixel size: 17μm
NETD: ≤60mk
Lens
FOV/Focal length: 25°×19°/15mm
Focus: Electric/Automatic
Measurement Features
Temperature range: -20°C-150°C;-20°C-350°C or-20°C-150°C; 100°C-650°C;
Accuracy: ±2°C or ±2% of reading for ambient temperature 15°C to 35°C
±3°C or ±3% of reading for ambient temperature -10°C to 10°C or 35°C to 50℃
Measuring distance: 0.5m-5m; 0.5m-10m; 5m-25m
Ethernet
Function: Wireless Communication and control
Ethernet Type: 1000Mbps
Video Streaming: 25Hz Y8＋（0Hz~25Hz） Raw data Y16
Protocol: RTSP，UDP，HTTP，TCP/IP，Onvif
IP distribution: Static IP, Dynamic IP
Networking mode: Directly connect to the computer for Y16 of no lower than 16Hz; connect via LAN (up to 32 sets) for Y16 of no lower than 16Hz.observe 9 sets synchronously.
Power system
Typical voltage: 12V
Environmental Parameters
Operating temp range: -10°C~50°C; -20°C~60°C
Storage temp range: -40°C~70°C
Humidity: 5%~95%. non-condensing
Shock: 10Hz~150Hz~10Hz 0.15mm （IEC 60068-2-6 ）
Vibration: 30g 11ms （IEC 60068-2-27）
Physical Characteristics
Dimensions: 88mm×60mm×60mm (lens included. interface excluded)
Weight: 410g
Mounting interface: M3 thread （for 4 sides）
External interfaces: Power, power indicator, Ethernet port, network reset port, alarm output IO, RS485
Standard accessories: Thermal module with a standard lens ×1, Power adapter ×1, CCC plug ×1, CE plug ×1, CD ×1, Network cable ×1
