Detector
Detector Type: 400×300@17μm
Spectral Range: 8μm~14μm
Lens
Focus: 25mm
Focusing: Manual
FOV: 14.6°×11.1°
Screen: Colorful 0.2″LCOS
Viewfinder: Monocular, diopter adjustable ±4
Frame: 50Hz
Digital Zoom: ×2, ×4
Color Palette: 5: Black hot, white hot, red hot 1, red hot 2, red hot 3
Functions: Cross cursor, Image enhancement, Wifi, Zoom, Charging indicator, Active indicator
Power
Battery: Internal Li-ion battery, 3.7V, 3200mAh
Working Time: ≥5h
Adapter: Standard USB power adapter, max 10W
Interface
USB: Charging
Video Ouput: MCX Connector, PAL/NTSC
Environment Characteristics
Working Temperature: -10℃~50℃
Storage Temperature: -30℃~60℃
Humidity: 10%~95%
Shock: 10Hz~150Hz~10Hz 0.15mm IEC60068-2-6
Encapsulation: IP66
Weight: 375g
Size: 168mm×67mm×62mm
Standard Accessories: thermal imager/ power adapter/ USB cable/ video cable /lens cap/ wrist strap/shoulder strap/soft drawstring bag/ user manual
Optional Accessory: 40mm extender lens（FOV:9.3°×7.0°）
Detection Range
Human: 1.8mx0.5m: 700m
Vehicle: 2.3mx2.3m: 1700m
Recognition Range
Human: 1.8mx0.5m: 350m
Vehicle:2.3mx2.3m: 700m
