Imaging and optics
Detector type: VOx, 7.5 to 14μm
Infrared resolution: 256×192@12μm
NETD: 45mK
Frame rate: 25Hz/ 9Hz
Focal length: 3.2mm
Field of view: 56°×48°
IFOV: 3.75mrad
Min. object distance: 0.3 m
D:S: 266:1
Focusing mode: Focus-free
Digital zoom: 1.1x to 8x
Measurement and analysis
Measurement range: Support auto-switching: -20°C to 150°C, 100°C to 550°C
Measurement accuracy: ±2°C or ±2%, whichever is greater
Analyzed target: Spot×2 ( Include Center spot), Area×3
Alarm: Full screen temperature threshold alarm (image and flash)
Parameter settings: Emissivity, reflected temperature, target distance
Others: Customized physical button×2
Image display
Display screen: 3.5" LCD
Image mode: IR, VIS, MIF and PIP
Color palettes: 6: White Hot, Black Hot, Iron Red, Hot Iron, Rainbow, Arctic
Image adjustment: Level span mode: Automatic, Semi-automatic, Manual
Digital camera: 5 MP
Functions
Laser: Laser (Indication, Ranging)
Recording function: Photo
Cloud Services: Available
Storage and transmission
Storage media: Built-in (16 GB)
Image storage: JPG with temp info
External interface: TYPE-C, UNC ¼"-20 (tripod mounting)
WIFI: Yes, it can be connected to the mobile terminal for image transmission
Power system
Battery type: Rechargeable lithium-ion battery, non-removable
Operating time: 4 hours
Charging mode: TYPE-C charging; PC/portable charger; Capable of charging while using
Charging time: 90% of full charge in 2.5 hours
Environmental parameters
Working temperature: -10°C to 50°C
IP rating: IP54
Drop: 1m drop test
Certification: CE, FCC, ROHS, KC, Anatel, IP54, 1m drop test, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS
Physical parameters
Hardware: Illuminator
Weight: 296g
Size: 138×89×34mm
Software kit: PC: ThermoTools; Mobile: Thermography (iOS/Android)
Standard: A device, Wrist strap, Carrying bag, Quick Start Guide, Power adapter, Adapter plug, Type-C USB cable, Data download card, Certificate of approval
Options: Tripod
