Function |
Range (*2) |
Resolution |
Input Resistance |
Accuracy(*1) |
|
DC Voltage |
500.00 mV |
10μV |
10MΩ or >10GΩ |
0.02 + 4 |
|
5.0000 V |
100μV |
10MΩ or >10GΩ |
0.02 + 4 |
|
|
50.000 V |
1mV |
11.11MΩ |
0.02 + 4 |
|
|
500.00 V |
10mV |
10.1MΩ |
0.02 + 4 |
|
|
1000.0 V |
100mV |
10MΩ |
0.02 + 4 |
|
|
Resistance |
500.00 Ω |
10mΩ |
0.83mA |
0.10 + 5 (*3) |
|
5.0000 kΩ |
100mΩ |
0.83mA |
0.10 + 3 (*3) |
|
|
50.000 kΩ |
1Ω |
83μA |
0.10 + 3 |
|
|
500.00 kΩ |
10Ω |
8.3μA |
0.10 + 3 |
|
|
5.0000 MΩ |
100Ω |
830nA |
0.10 + 3 |
|
|
50.000 MΩ |
1kΩ |
560nA//10 MΩ |
0.30 + 3 |
|
|
DC Current |
500.00 μA |
10nA |
0.06V max. |
0.05 + 5 |
|
5.0000 mA |
100nA |
0.6V max. |
0.05 + 4 |
|
|
50.000 mA |
1μA |
0.14V max. |
0.05 + 4 |
|
|
|
10μA |
1.4V max. |
0.10 + 4 |
|
|
|
100μA |
0.5V max. |
0.25 + 5 |
|
|
|
1mA |
0.8V max. |
0.25 + 5 |
|
|
Continuity |
5000.0 Ω |
100mΩ |
0.83mA |
0.10 + 5 |
|
Diode Test |
5.0000 V |
100μV |
0.83mA |
0.05 + 5 |
|
Capacitance |
5.000 nF: 0.5~1nF |
0.001nF |
8.3μA |
2.00 + 20 |
|
5.000 nF: 1~5nF |
0.001nF |
8.3μA |
2.00 + 10 |
|
|
50.00 nF: 5~10nF |
0.01nF |
8.3μA |
2.00 + 30 |
|
|
50.00 nF: 10~50nF |
0.01nF |
8.3μA |
2.00 + 10 |
|
|
500.0 nF |
0.1nF |
83μA |
2.00 + 4 |
|
|
5.000 μF |
1nF |
0.56mA |
2.00 + 4 |
|
|
50.00 μF |
10nF |
0.83mA |
2.00 + 4 |
|
|
True RMS Volatge (*4/*5/*6) |
500.00 mV |
10μV |
30Hz – 50Hz |
1.00 + 40 |
|
50Hz – 10kHz |
0.50 + 40 |
|||
|
10kHz – 30kHz |
2.00 + 60 |
|||
|
30kHz – 100kHz |
3.00 + 120 |
|||
|
5.0000 V |
100μV |
30Hz – 50Hz |
1.00 + 20 |
|
|
50Hz – 10kHz |
0.35 + 15 |
|||
|
10kHz – 30kHz |
1.00 + 20 |
|||
|
30kHz – 100kHz |
3.00 + 50 |
|||
|
50.000 V |
1mV |
30Hz – 50Hz |
1.00 + 20 |
|
|
50Hz – 10kHz |
|
Function |
Range (*2) |
Resolution |
Input Resistance |
Accuracy(*1) |
|
DC Voltage |
500.00 mV |
10μV |
10MΩ or >10GΩ |
0.02 + 4 |
|
5.0000 V |
100μV |
10MΩ or >10GΩ |
0.02 + 4 |
|
|
50.000 V |
1mV |
11.11MΩ |
0.02 + 4 |
|
|
500.00 V |
10mV |
10.1MΩ |
0.02 + 4 |
|
|
1000.0 V |
100mV |
10MΩ |
0.02 + 4 |
|
|
Resistance |
500.00 Ω |
10mΩ |
0.83mA |
0.10 + 5 (*3) |
|
5.0000 kΩ |
100mΩ |
0.83mA |
0.10 + 3 (*3) |
|
|
50.000 kΩ |
1Ω |
83μA |
0.10 + 3 |
|
|
500.00 kΩ |
10Ω |
8.3μA |
0.10 + 3 |
|
|
5.0000 MΩ |
100Ω |
830nA |
0.10 + 3 |
|
|
50.000 MΩ |
1kΩ |
560nA//10 MΩ |
0.30 + 3 |
|
|
DC Current |
500.00 μA |
10nA |
0.06V max. |
0.05 + 5 |
|
5.0000 mA |
100nA |
0.6V max. |
0.05 + 4 |
|
|
50.000 mA |
1μA |
0.14V max. |
0.05 + 4 |
|
|
|
10μA |
1.4V max. |
0.10 + 4 |
|
|
|
100μA |
0.5V max. |
0.25 + 5 |
|
|
|
1mA |
0.8V max. |
0.25 + 5 |
|
|
Continuity |
5000.0 Ω |
100mΩ |
0.83mA |
0.10 + 5 |
|
Diode Test |
5.0000 V |
100μV |
0.83mA |
0.05 + 5 |
|
Capacitance |
5.000 nF: 0.5~1nF |
0.001nF |
8.3μA |
2.00 + 20 |
|
5.000 nF: 1~5nF |
0.001nF |
8.3μA |
2.00 + 10 |
|
|
50.00 nF: 5~10nF |
0.01nF |
8.3μA |
2.00 + 30 |
|
|
50.00 nF: 10~50nF |
0.01nF |
8.3μA |
2.00 + 10 |
|
|
500.0 nF |
0.1nF |
83μA |
2.00 + 4 |
|
|
5.000 μF |
1nF |
0.56mA |
2.00 + 4 |
|
|
50.00 μF |
10nF |
0.83mA |
2.00 + 4 |
|
|
True RMS Volatge (*4/*5/*6) |
500.00 mV |
10μV |
30Hz – 50Hz |
1.00 + 40 |
|
50Hz – 10kHz |
0.50 + 40 |
|||
|
10kHz – 30kHz |
2.00 + 60 |
|||
|
30kHz – 100kHz |
3.00 + 120 |
|||
|
5.0000 V |
100μV |
30Hz – 50Hz |
1.00 + 20 |
|
|
50Hz – 10kHz |
0.35 + 15 |
|||
|
10kHz – 30kHz |
1.00 + 20 |
|||
|
30kHz – 100kHz |
3.00 + 50 |
|||
|
50.000 V |
1mV |
30Hz – 50Hz |
1.00 + 20 |
|
|
50Hz – 10kHz |
0.35 + 15 |
