OUTPUT RATINGS
Independent: 0 V to 32 V, 0 A to 3 A
Series (2 units with series function): 0 V to 64 V, 0 A to 3 A
Parallel (2 units with parallel function): 0 V to 32 V, 0 A to 6 A
CONSTANT VOLTAGE OPERATION
Line Regulation: ≤ 0.01 % + 3 mV
Load Regulation: ≤ 0.01 % + 3 mV
Ripple & Noise: ≤ 0.5 mVrms (5 Hz to 1 MHz)
Setting Range: 0 V to 33.6 V
Setting/Readback Accuracy: ± (0.03 % of reading + 10 mV)
Setting/Readback Resolution: 1 mV / 0.1 mV
Maximum Remote Sensing Compensation Voltage: 1 V
Recovery Time: ≤ 100 µs (50 % load change, minimum load 0.5 A)
Temperature Coefficient: ≤ 300 ppm/°C
CONSTANT CURRENT OPERATION
Line Regulation: ≤ 0.2 % + 3 mA
Load Regulation: ≤ 0.2 % + 3 mA
Ripple & Noise: ≤ 2 mArms
Setting Range: 0 A to 3.15 A
Setting/Readback Accuracy: ± (0.3 % of reading + 10 mA)
Setting/Readback Resolution: 0.1 mA / 0.01 mA
Temperature Coefficient: ≤ 300 ppm/°C
PROTECTION
OVP Range: OFF, ON (1.8 V to 35.2 V)
OVP Resolution: 100 mV
OVP Accuracy: ≤ ± 100 mV
OCP Range: OFF, ON (0.15 A to 3.3 A)
OCP Resolution: 10 mA
OCP Accuracy: ≤ ± 20 mA
DISPLAY
LCD: 2.4-inch TFT LCD
INSULATION
Chassis and Terminal: 20 MΩ or above (DC 500 V)
Chassis and AC Cord: 30 MΩ or above (DC 500 V)
ENVIRONMENT
Operation Environment: Indoor use, Altitude: ≤ 2000 m; Ambient temperature: 0 °C to 40 °C; Relative humidity: ≤ 80 %; Installation category: II; Pollution degree: 2
Storage Environment: Ambient temperature: -10 °C to 70 °C; Relative humidity: ≤ 70 %
POWER SOURCE AND POWER CONSUMPTION
Power Source: AC (100 V, 120 V, 220 V, 240 V) ± 10 %, 50 or 60 Hz
Power Consumption: 300 VA
DIMENSIONS AND WEIGHT
Dimensions & Weight: 107 mm × 124 mm × 313 mm (W x H x D); Approx. 5.2 kg
