Pitch: 2.54 mm (0.1 in)
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 2.800 g
Housing Color: Beige
Contact Gender: Pin (Male)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 500 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: Solder Pin
Mating Post Length: 6.35 mm (0.25 in)
Flammability Rating: UL 94 V-0
Number of Positions: 14 Position
Insulation Resistance: 10 GOhms
Termination Post Length: 2.9 mm (0.114 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
