Pitch: 2 mm (0.079 in)
Unit Weight: 460 mg
REACH - SVHC: Details
Housing Color: Black
Latching Type: Locking Latch
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 1 Row
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Polyester
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 3 mm (0.118 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
