■ Specifications:
Working voltage range: 3.3 kV to 77 kV (Non-contact type for 11 kV or higher)
Operating temperature range: －20℃～＋40℃
Frequency: 50/60Hz
Battery: LR44(1.5V) × 2 pcs
Dielectric strength: Between tip part and grip of detector: 20 kVAC, 1 min
(Leakage current: 1 mA or less)
Detection performance:
- Operation starting voltage: 400 V ± 20%
- Detectable distance: 5 cm at 3.3 kV, 10 cm at 6.6 kV
Operation status display:
- Light: Can be confirmed at the distance of 50 cm in the luminance of 8,000 lux
- Sound: 50dB or more (1m apart)
Dimensions: 155mm
Weight: 85g
＊Without the casing
