Max. cutting height: 70mm
Width of cutting area: 1800mm
Length of cutting area: 1800mm
Length of cutting table: 820mm
Cutting method: Knife reciprocation
Cutting speed: 1～50m/min
Drill:
Standard Marking Drill：1.5～3.0mm
Option Reinforced punch: №1～3：3～20mm
Knife sharpening:Sharpening belt
Vacuum method: Turbo type automatic suction pressure control
Operation side:
Standard: Left side
Option: Right side
Cutting conveyor: Nylon bristels
Safety stop device: Standard: Bumper type
Option: Sensor recognition
Power: 3-phase AC200V ±10％ 50/60Hz
PC for operation: Universal PC/OS： Windows10, 64bit
Display: 20 inches, LCD
Data entry media: LAN, USB
Data format: GBR/CAM/NC/CUT/KMC
Language: Japanese / English / Chinese / Vietnamese / Korean
Air supply: 0.5Mpa、70NL/min.(Option Knife cooler：350NL/min.)
Sound: ＜75db
Weight: 4500kg
Usage environment: Temperature：10～43℃
Humidity：＜95％
