Infrared Image
IR Resolution: 96 × 96 (9,216 pixels)
ODE: Yes
Distance to Spot Ratio (D:S): 15:1
NETD: < 50 mK (@ 25 °C, F# = 1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 – 14 μm
Focal Length: 1.35 mm
F-number: F1.0
Field of View (FOV): 50° × 50°
Spatial Resolution (IFOV): 8.89 mrad
Minimum Focus Distance: 0.1 m (0.33 ft)
Focus Mode: Focus Free
Image Display
Display: 2.4" LCD screen, 240 × 320 resolution
Image Modes: Thermal
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Blue Yellow
Color Alarm: Above alarm, Below alarm
Measurement and Analysis
Object Temperature Range:
Range 1: -20 °C to 150 °C (-4 °F to 302 °F)
Range 2: 100 °C to 550 °C (212 °F to 1022 °F)
Accuracy: ±2 °C / ±3.6 °F or ±2% at ambient temperature 25 °C (77 °F) and object temperature above 0 °C (32 °F)
Thermometer Mode: Yes
Measurement Tools: Center spot, Max spot, Min spot
Level and Span Mode: Auto
Data Storage and Communication
Storage Media: Built-in 80 MB
Image Storage Capacity: Approx. 500–1,000 images (actual storage may vary depending on scene complexity)
General
USB Interface: USB Type-C
Battery Type: Rechargeable Li-ion battery
Battery Charging Time: Approx. 3 hours (adapter output: 5 V / 2 A)
Battery Operating Time: Approx. 14 hours
Protection Level: IP54
Drop Test Height: 1 m (3.28 ft)
Working Temperature Range: -10 °C to 50 °C (14 °F to 122 °F)
Storage Temperature Range: -40 °C to 70 °C (-40 °F to 158 °F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 228 g (0.529 lb)
Dimensions: 196 × 59 × 78 mm
Tripod Mounting: UNC 1/4”-20
