Viewing head: Compensation Free Binocular Head. Inclined at 45 ° ( 50mm -75mm )
Eyepiece: WF10X/22mm; WF10X/20mm with reticule 0.1mm
Nosepiece: Quadruple nosepiece
Objective: Infinity metallurgical objectives: 4X/0.1W.D.25mm; 10X/ 0.25W.D .12mm; 20X/0.4W.D .10mm; 40X/0.6W.D. 7.1mm
Stage: Double layers mechanical stage; Stage size: 242mm × 172mm; Central stage: Φ110mm; Moving range: 75mm × 50mm
Focusing: Coaxial coarse & fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value 0.002mm
Illumination: Epi-Kohler illumination. With aperture iris diaphragm and field iris diaphragm. 12V/30W.AC85V-230V Adjustable brightness
Filter: Blue, green, yellow
Polarizing outfit: Analyzer rotatable 360° ,polarizer & Analyzer can be slid in/out of the optical path
Checking tool: 0.01mm micrometer
Optional Accessory:
- 1.3, 2.0, 3.0, 5.0 Megapixels CMOS electronic eyepiece
- Photography attachment
