Specification
- Feature: Record load current of 50Hz/60Hz lines Record leak current
- Measurement items: AC Current (2 channels)
- Measurement range:
+ When Using 9669 :1000A range
+ When Using CT6500 :50.00A/ 500.0A range
+ When Using 9695-02 :5.000A/ 50.00A range
+ When Using 9675 :500.0mA/ 5.000A range
+ When Using 9657-10 :500.0mA/ 5.000A range
- Basic Accuracy: ±0.5%rdg. ±5dgt.+Clamp sensor accuracy
- Waterproof and dustproof: Not waterproof
- Operating temperature and humidity: -0°C(32°F) to 50°C(122°F) , 80%rh or less (non-condensating)
- Dimensions & Mass: 79x70x37mm,165g
- Power supply: LR6 (AA) Alkaline battery 1.5V × 2
- Battery life:
+ Case 1 : Approx. 2 years
+ Case 2: Approx. 2 months
- Accessories: LR6 (AA) Alkaline battery 1.5V × 2, Instruction manual ×1, Operation manual×1
| Features | Record load current of 50Hz/60Hz lines Record leak current |
| Measurement items | AC Current (2 channels) |
| Measurement range | When Using 9669 :1000A range When Using CT6500 :50.00A/ 500.0A range When Using 9695-02 :5.000A/ 50.00A range When Using 9675 :500.0mA/ 5.000A range When Using 9657-10 :500.0mA/ 5.000A range |
| Basic Accuracy | ±0.5%rdg. ±5dgt.+Clamp sensor accuracy |
| Waterproof and dustproof | Not waterproof |
| Operating temperature and humidity | -0°C(32°F) to 50°C(122°F) , 80%rh or less (non-condensating) |
| Dimensions & Mass | Approx. 79mm(3.11in)W×70mm(2.76in) H×37mm(1.46in)D, 165g(5.8oz) |
| Power supply | LR6 (AA) Alkaline battery 1.5V × 2 |
| Battery life | Case 1 : Approx. 1 years (1min. recording interval, power-saving mode, Instantaneous recording, environmental temp.20°C) Case 2: Approx. 1 months (1sec. recording interval, power-saving mode, Instantaneous recording, environmental temp.20°C) |
| Accessories | LR6 (AA) Alkaline battery 1.5V × 2 Instruction manual ×1, Operation manual×1 |
