Pitch: 2.54 mm (0.1 in)
Row Spacing: 2.54 mm (0.1 in)
Unit Weight: 2.360 g
Housing Color: Black
Contact Gender: Socket (Female)
Current Rating: 1 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Voltage Rating: 200 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 20 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 2.5 mm (0.098 in)
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
