WIRELESS CONNECTIVITY
Radio/Range: 2.4 to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v4.2; Class 1: 50m(164ft) line of sight
ELECTRICAL
Battery: 750 mAh Li-ion minimum, replaceable
Number of Scans: Up to 3,600 scans per full charge
Expected Hours of Operation: 20 hours at 3 scans per minute
Expected Charge Time: 3 hours
Interface: HID keyboard wedge, Serial Port
Profile (SPP)
Keyboard: Support 84 international keyboards
User Interactions: Good decode LEDs, Battery status LED, Bluetooth connectivity LED,
Beeper (adjustable tone and volume), Scan button, Secondary programmable button
MECHANICAL/ELECTRICAL
Dimensions (LxWxH): 120 x 48 x 22 mm (4.7 x 1.9 x 0.9 in)
Weight: < 100 g (3.5oz)
ENVIRONMENTAL
Temperature: Operating: 0°C to 50°C (32°F to 122°F)
While Charging: 0°C to 40°C (32°F to 104°F)
Humidity: 0 to 95% relative humidity, non-condensing
Drop: Designed to withstand 30 1.4 m (4’) drops to concrete
Environmental Sealing: IP52
Light Levels: 0 to 100,000 lux (9,290 foot-candles)
SCAN PERFORMANCE
Scan Pattern: Area Image (1040*720 pixel array)
Frame Per Second: 60FPS
Scan Angle: Horizontal 41.4°; Vertical 32.2°
Symbol Contrast: as low as 15%
Illumination: White
Aimer: Red Bar
