DC withstand voltage measurement
Voltage range: 0~10000V
Voltage output resolution: 0.001kV
Voltage output accuracy: ±(3%+5 counts)
Current measurement: 0~5mA
Current resolution: 0.01μA
Current accuracy: ±(2%+ 2 counts)
Insulation resistance test
Voltage range: 0~3000V
Voltage resolution: 0.001kV
Voltage accuracy: ±(3%+ 5 counts)
Resistance range: 0.1MΩ~99GΩ
Resistance accuracy:
±(2% display value +3 counts)（100kΩ-999MΩ）
±(5% display value +3 counts)（1.00GΩ-9.99GΩ；
±(20% display value +3 counts)（10GΩ-99GΩ）
Ground resistance test
Current range: 10A~80A
Current resolution: 0.01A
Current accuracy: ±(2%+5 counts)
Resistance range:
0~600.00mΩ (10.00A~20.00A)；
0~300.00mΩ (20.01A~30.00A);
0~200.00mΩ (30.01A~40.00A)；
0~150.00mΩ (40.01A~50.00A);
0~120.00mΩ (50.01A~60.00A);
0~100.00mΩ (60.01A~70A)
0~80.00mΩ (70.01A~80A)
Resistance resolution: 0.001mΩ
Resistance accuracy: ±(2%+3 counts)
Size: 427mm*406mm*87mm
Accessories: HT9933, HT9950, HT9900, JK381-10P-T, HT9800, power cord
