Max.Load: 2000KN
Load Accuracy: ≤± 1%
Load Range: 2%~100% FS
Load Resolution: 1/300000
Deformation Measurement Range: 2%~100%FS
Deformation Indication Relative Error: ≤ ±0.5%
Displacement Resolution: 0.01mm
Displacement Indication Relative Error: ≤ ±0.5%
Max. Piston Moving Speed: 0~100mm/min Stepless Speed Adjusting
Clamping Method: Hydraulic Automatic Clamping
Round Specimen Clamping Range: Φ10~Φ30 mm, Φ30~Φ50 mm, Φ50~Φ70 mm
Flat Specimen Clamping Range: 0~25mm, 25~50mm
Flat Specimen Clamping Width: 140mm
Flat Specimen Clamping Length: 160mm
Compression Plate Size: Φ240mm
Bending Roller Distance: 450mm
Width Of Bending Rollers: 120mm
Host Dimension: 1330*880*2625mm
Control Cabinet Dimension: 1000*1005*1500mm
Host Weight: 7Tons
Power Supply: 3-Phase 4-Wires, AC 380V, 50Hz, 9kW
