DC Voltage:
50.000mV; ±(0.05%rdg+30dgt); 10MΩ // <100pF; 1000VDC/ACrms
500.00mV/ 5.0000V/ 50.000V/ 500.00V/ 1000.0V; ±(0.05%rdg+5dgt); 10MΩ // <100pF; 1000VDC/ACrms
AC TRMS Voltage:
50.000mV/ 500.00mV; ±(0.7%rdg+20dgt) (40Hz ÷ 70Hz) ±(1.5%rdg+40dgt)
(71Hz ÷ 10kHz); 10MΩ // <100pF; 1000VDC/ACrms
5.0000V/ 50.000V/ 500.00V/ 1000.0V; ±(0.5%rdg+20dgt)(40Hz ÷ 70Hz)
±(1.5%rdg+40dgt)(71Hz ÷ 1kHz;)±(3.0%rdg+80dgt)(1.001kHz ÷ 10kHz); 10MΩ // <100pF; 1000VDC/ACrms
DC Current: 50.000mA/ 1.0000A; ±(0.05%rdg + 5dgt) 1min (input A) 10min (input mA); max 440mA
AC TRMS Current:
50.000mA/ 1.0000A; ±(1.0%rdg + 20dgt)(40Hz ÷ 70Hz)±(2.0%rdg + 20dgt)
(71Hz ÷ 10kHz); 1min (input A)10min (input mA); max 440mA
Resistance
500.00Ω; ±(0.2%rdg+30dgt); 1mA; 1000VDC/ACrms
5.0000kΩ (100µA)/ 50.000kΩ(10µA); ±(0.2%rdg+10dgt); 1000VDC/ACrms
500.00kΩ; ±(0.5%rdg+10dgt); 1µA; 1000VDC/ACrms
5.0000MΩ; ±(1.0%rdg+10dgt); 100nA; 1000VDC/ACrms
50.000MΩ; ±(2.0%rdg+10dgt); 10nA; 1000VDC/ACrms
Continguity Test: 500.0Ω; ±(0.1%rdg+30dgt); approx 3.5V; 1000VDC/ACrms
DIODE Test: 2.000V; ±(1.0%rdg+10dgt); approx ±3V; 1000VDC/ACrms
Frequency AC Voltage/Currewnt: 500.00Hz/ 5.0000kHz/ 50.000kHz/ 100.00kHz; ±3dgt; 1000VDC/ACrms max 440mA
AC mV: 50.000mV/500.00mV; 5Hz ÷ 10kHz: 10mV; 10kHz ÷ 100kHz :100mV
AC V: 5.0000V; 5Hz ÷ 10kHz : 1V; 10kHz ÷ 100kHz : 1V
50.000V/ 500.00V/ 1000.0V; 5Hz ÷ 10kHz : 1V; 10kHz ÷ 100kHz: not specified
AC A: 50.000mA; 5Hz ÷ 10kHz :10mA; 10kHz ÷ 100kHz: not specified
1.000A ; 5Hz ÷ 10kHz: 300mA; 10kHz ÷ 100kHz: not specified
GENERATED DC CURRENT – Programmable output
0.000÷20.000mA/ 4.000÷20.000mA; ±(0.05%rdg+5dgt); max 440mA
POWER (Loop current)
LOOP (30V / 1.25kΩ)/ 250Ω HART (24V / 1kΩ) ; 50.000mA;±(0.05%rdg + 5dgt); max 440mA
Accessories:
2 Strap with magnetic terminal
Anti-shock protection shell
Pair of Leads YAAMK0000HT0
Pair of Test Leads YAAMK0001HT0
Batteries and user manual
