DC VOLTAGE: 400.0mV/ 4.000V/ 40.00V/ 400.0V/ 600V; ±(1.0%rdg+3dgt); 600VDC/ACrms
AC TRMS VOLTAGE: 4.000V/ 40.00V/ 400.0V/ 600V; ±(1.0%rdg+3dgt); 600VDC/ACrms
DC CURRENT:
400.0μA/ 4000μA/ 40.00mA/ 400.0mA; ±(1.0%rdg+3dgt) Fast Fuse 0.5A/600V (inputs mA, μA)
4.000A/ 10.00A; ±(1.2%rdg+3dgt); Fast Fuse 10A/600V (input 10A)
AC TRMS CURRENT :
400.0μA/ 4000μA/ 40.00mA/ 400.0mA; ±(1.2%rdg+3dgt); Fast Fuse 0.5A/600V (inputs mA, μA)
6.000A/ 10.00A; ±(1.8%rdg+5dgt); Fast Fuse 10A/600V (input 10A)
DIODE TEST: <0.35mA; 3VDC
Resistance and Continuity Test:
400.0Ω/ 4.000kΩ/ 40.00kΩ/ 400.0kΩ/ 4.000MΩ; ±(1.5%rdg+5dgt); <50Ω; 600VDC/ACrms
40.00M; ± (2.5%rdg+20dgt); <50Ω; 600VDC/ACrms
FREQUENCY (Electronic circuits): 10.00Hz 10kHz; (1.2%rdg); 15Vrms
DUTY CYCLE: 0.1 – 99.9%; ±(1.2%rdg + 2dgt)
CAPACITANCE:
40.00nF/ 400.0nF; (4.5rdg+10dgt); 600VDC/ACrms
4.000F/ 40.00F/ 400.0F; (3.0rdg+5dgt); 600VDC/ACrms
4000F; (5.0rdg+5dgt); 600VDC/ACrms
Display: LCD, 4 dgt 4000 counts, sign and decimal point; Automatic polarity indication; Backlight; “OL” over range indication; Response time: 3/s
Features: Data HOLD; MAX/MIN; Built-in white torch; Auto Power OFF after 15 minutes of idleness
Max altitude of use: 2000m
Pollution degree: 2
Insulation: double insulation
Power supply: 2x1.5V alkaline batteries type AAA LR03
Dimensions (L x W x H): 120 x 65 x 45mm
Weight (included battery): 200g
Accessories:
Carrying bag
Pair of Leads YAAMK0000HT0
Batteries and user manual
