1. IMAGING PERFORMANCE
Detector type: UFPA
Spectral range: 8 ÷14um
Resolution / Pxl size: 80x80 pxl / 34um
Thermal sensitivity: <0.1 °C @ 30°C
Field of View (FOV): 21° x 21° (7.5mm lens)
Minimum focal distance: 0.5m
IFOV (@1m) :4.53mrad
D:S ratio: 74:1
Focusing : Automatic
Image frequency: 50Hz
Color palettes: 5 (Iron, Rainbow, Grey, Grey Inverted, Feather)
Display type: 2.8” TFT color 320x240pxl
2. MEASUREMENT
Temperature range: -20°C ÷ 380°C (-4°F ÷ 716°F)
Measurement unit :°C, °F, K
Accuracy: ±2%rdg or ±2°C
Measurement cursors: 3 (MIN, MAX, FIXED)
Built-in illuminator: White light LED
Measurement modes :Automatic / Manual
Emissivity correction: 0.01 ÷ 1.00
Measurement features: Automatic correction based on emissivity
3. IMAGE STORAGE AND EXTERNAL INTERFACE
Internal memory: Max 20 location
File format: BMP
External interface: Bluetooth BLE 4.0
4. MAINS SUPPLY T HT 44 T HT 42
Battery type: Rechargeable Li-ION, 3,7V 1300mAh
Charging system: Micro USB interface on camera
Battery life: 5 hours (Bluetooth OFF), 4 hours (Bluetooth ON)
External power: External adapter 100/240VAC (50/60Hz) / 5VDC
5. GENERAL FEATURES
Operating temperature: -10°C ÷ 45°C (14°F ÷ 113°F)
Operating humidity: <80%RH
Storage temperature: -20°C ÷ 60°C C (-4°F ÷ 140°F)
Storage humidity: <80%RH
Encapsulation: IP54 according with IEC529
Drop test: 2m (7ft)
Dimensions (L x W x H): 180 x 60 x 75mm (7 x 3 x 3in)
Weight(battery included): 260g (9 ounces)
Standard accessories:
Rechargeable battery
User Manual
Power supply cattery charger
ISO9000 calibration certificate
Carrying bag
