Min measuring unit: 0.125µm(option:0.0625µm)
Load: 1.0 (9.8N)、2.0Kgf(19.6N)、3.0Kgf(29.4N)、5.0Kgf(49.0N)、10.0Kgf(98.0N)、20.0Kgf(196N)、30.0Kgf(294N)、50.0Kgf(490N)
Hardness measuring range: 8~2900HV
method of Load applied: Automatic loading, unloading
Objective, indenter exchange: Manual/Automatic
Objective:
Number: two
Standard： 10X、20X
Test microscope magnification: Standard：100X、200X
Dwell time: 0~99S（per second as a unit，any entering）
Data output: Read by LCD，saved in USB flash disk as EXCEL document
Max Height of Specimen: 180MM
Distance of Indenter to outer wall: 160mm
Power supply: AC220V+5%，50-60Hz
Overall Dimension: 580*240*660mm
Net weight: About 40Kg
