Measure Range: 0.75~400 mm （Steel）
Resolution: 0.001mm/0.0001inches
Measuring Period: 4 times per second
Calibration Mode: Probe Calibration & Two Point Calibration
Measurement Mode: P-E, I-E, E-E
Measuring Mode: Single point, scan, min/max capture, differential, alarm
Display: English / Chinese selectable, FSTN LCD Display with backlight
Communication: Bluetooth & Mini-USB interface, virtual serial port protocol
Power Supply: 3.7V Li-Ion chargeable battery
Usage Temperature: -10 ~ 50 °C
Size: 157mm*78mm*37mm
Shell Material: ABS & PC alloy
Sound Velocity Range: 1 ~ 19999 m/s
Accuracy: 0.03mm or 0.3%*H
Probe Frequency: 2MHz，3MHz，5MHz，7.5MHz
Calibration block: 4.000mm（Steel）
Gain Adjustable: 16 Stages
Data Storage: 1000 measurements, including thickness, sound velocity, time, etc.
Display Content: Thickness, Sound velocity, Stability,Battery, Measuring Mode, etc.
Print: Optional portable Bluetooth thermal printers
Power off: Timeout power off, low battery power off
Storage Temperature: -30 ~ 60 °C
Weight: About 260g
Box Material: ABS (IK08/IP67)
