Current measurement: (0-25)mA
Accuracy:±(0.02%R.D+0.005%F.S)
Voltage measurement: (0-25)V
Accuracy:±(0.02%R.D+0.005%F.S)
◆ Temperature compensating range:(0-50)℃
◆ DC output:DC24V(≤30mA) Accuracy: ±1%F.S
◆ Power supply:7.4Vdc Lithium battery power supply and special charger
◆ Connection:M20×1.5 or 1/4"NPT male thread(or customized)
◆ Dimensions:Φ95mmx49mm. Total Height:166mm
◆ Weight:0.75kg
Features
◆ Equipped with rugged ABS plastic
◆ Pressure-transmitting medium including air, oil, and water
◆ 6/5-digit LCD screen with backlight
◆ Nine Pressure Units Selectable: kPa, Pa, psi, kgf/cm2, bar, mbar,mmH2O, mmHg, MPa
◆ Zero point, full scale calibration function
◆ 7.4Vdc Lithium battery and special charger
◆ Overload and short circuit protection
◆ Light weight, small size, easy operation
◆ Rapid in operation, compatible with computer software
◆ Support Hart Version 5
◆ With max/min Values functions
◆ CE approved
