Force range: 1～20kN
Extrusion stroke: 250mm
Force value display: touch screen display
Extrusion head: Extrusion head area ≥20cm²
Extrusion degree: Extrusion pressure reaches 13±0.2kN, keep for 1min
Test space: 200x200x200mm (width x depth x height)
External material: A3 steel plate and painted, thickness 1.5mm
Material of inner box: SUS#304, thickness 1.2mm
Steel needle: φ2mm～φ8mm high temperature resistant steel needle, the length is 100mm (can be specified)
Inner box size: 520x450x560mm (width x depth x height)
Dimensions: 800x700x1720mm (width x depth x height, including door lock)
Pressure relief door size: 200x200mm;
Smoke exhaust pipe: diameter φ100mm, located at the back of the box
